HeatLab 3-Zone Wireless System & Natural Gas Flow Modulation Package
Maximize your comfort and slash energy bills with the ultimate HVAC optimization bundle.
This premium package combines HeatLab's 3-Zone Wireless Control System with the Natural Gas Flow Modulation Controller to deliver real-time, precision heating and cooling tailored to your space.


🌟 Key Benefits
Immediate Savings: Stops heating or cooling unoccupied rooms to cut energy waste instantly.
Longer Equipment Life: Reduces furnace runtime and cycling to minimize wear and tear.
Personalized Comfort: Maintains stable, customized temperatures across three distinct areas.
True Wireless Freedom: Eliminates the need to run messy thermostat wires through walls.


⚙️ How the Package Works
The Zone System constantly monitors and identifies the specific temperature needs of each room.
The Modulation Controller adjusts natural gas flow in real-time to match that exact demand.
The Result is a highly responsive, ultra-efficient system that eliminates temperature swings.

⚠️ Important Compatibility Note: The Natural Gas Flow Modulation Controller cannot be sold separately. It must be used alongside a HeatLab Zone Control System.


📦 What is Included

1. Zone Control System Components
1 Wireless Zone System Communication Module
1 Main Air Dampers Communication Module
3 Wireless Thermostats
3 Plug-In Motorized Air Flow Dampers (Standard 4"–8" sizes included)
3 RJ45 Plug-In Cables (8-meter length)

2. Natural Gas Flow Modulation Controller
1 Precision Gas Flow Valve Motorized Controller


🛠️ Technical Features & Specifications

System Capabilities & Compatibility
System Types: Single-stage, multi-stage, heat pump (up to 3H/2C), or dual-fuel systems.
Furnace Fit: Compatible with any standard furnace and variable speed systems.
Scalability: Supports up to 20 zones (up to 10 dampers operating simultaneously per zone).
Smart Home Integrations: Works seamlessly with Alexa Echo, Google Home, smartphone apps, and tablets.

Advanced Controls
Bypass & Fan: Automatic bypass air damper control with separate circulation fan management.
Pressure Monitoring: Built-in static pressure monitoring.
Optional Add-ons: Static Pressure Sensor, Duct Temperature Probe.

Motorized Zone Damper Specifications
Material: Heavy-duty galvanized steel tube sleeve (26-gauge for 4"–12"; 24-gauge for 12"–14").
Damper Blade: High-quality gasket sandwiched between two steel blades.
Operation: 24VAC Power Open / Power Close motor (UL-approved fire-retardant casing).
Torque: Heavy-duty 88 lbs. rating.
Configurations: Available in Normally Open (NO) or Normally Closed (NC).
Sleeve Lengths: 4"–8" (9"L) | 10"–11" (11"L) | 12"–14" (14"L) | 16" (18"L).
Note: Standard package covers 4"–8" dampers. Sizes 6" and above incur a price increase.

Gas Modulation Valve Technical Details
Model Number: HL-MVC-1
Style: Controller with Motorized Valve (0.5″ connection)
Material: Premium Brass
Voltage: 24V AC
Dimensions: 16.5 x 13.1 x 11.1 cm
Weight: 2.2 lbs (1 kg)
Power: Hardwired (No batteries required)


🛡️ Warranty & Risk-Free Return Policy
5-Year Warranty: Long-term protection on your equipment investment.
45-Day Money-Back Guarantee: If you are unsatisfied or do not receive your product and installation within 45 days, you qualify for an immediate, hassle-free refund.
